XMC-1553

Form Factor: PMC/XMC
Category: Avionics Data Bus
Supplier: Alta Data Technologies (ADT)
Application(s): 地上設備

特徴

・チャンネル数: 1チャンネル~最大10チャンネル
・4 Lane PCI Express 2.1 Gen 2, 5 GHz
・VITA 42 XMC Single Width. XMC 2.0 Optional
・Loop -Back & User BIT, Dual Temp Sensors
・Optional Rear Panel XMC P6 Connector
・Dual and Full Function 1553 Channels
・Weight: 8-10oz
・3.3V Power (Estimated @ Max Bandwidth) 8-13W with max channels. Estimate 0.8W Per Channel. These numbers are subject to change with Alta factory testing.

・Parts Temp (C) : -55 to +120 Storage, 0 to +70 Commercial, -40 to + 85 Extended
・8 Avionics, 2 RS-485 Discretes, Triggers
・IRIG-B RX PAM, TTL/RS-485 PPS Time Sync
・IPC Class 3 and ISO 9001:2015 Processes



データシート: XMC-1553.pdf
メーカーページ: ここをクリック.
