PMC-1553

Form Factor: PMC/XMC
Category: Avionics Data Bus
Supplier: Alta Data Technologies (ADT)
Application(s): 航空機搭載向け, 地上設備

特徴
チャンネル数: 1~4チャンネル
32-Bit PCI 33/66MHz/PCI-X Compatible
・PCI-SIG PCI 2.1 Compliant
・ANSI/VITA 20-2001 Compliant
・One Megabyte RAM per Channel
・Common Data Packets (CDPs) for all BC, RT and Monitor Functions – Industry First
・MIL-STD-1553B Notice II & IV
・MIL-STD-1760,1553A and Link-16
・Weight: 4oz/120grams
・Power (Estimated @ Max Bandwidth)
・1CH@5.5W, 2CH@6.5W, 3CH@7.5W, 4CH@8.5W
・Parts Temp (C) : -55 to +120 Storage, 0 to +70 Commercial, -40 to +85 Extended
・SCSI 3 Cable Assembly with 1553 3-Plug Stub Cables Provided. DB50 Optional for Trig/Clk/IO.
・14 Avionics and Two RS-485 Discretes
・1 Channel 1760 Ext RT Address Power-Up
・Loop-Back & User BIT, Dual Temp Sensors
・IRIG-B RX PAM and TX/RX PPS Time Sync
・IPC Class 3 and ISO 9001:2008 Processes



データシート: PMC-1553.pdf
メーカーページ: ここをクリック.
